Modular garage floor tiles are one of the quickest and most effective ways to completely transform a
garage floor.
Unlike traditional flooring systems, interlocking garage floor tiles can be installed directly over most
existing concrete floors without the need for adhesives, specialist coatings or lengthy curing times.
The result is a hard-wearing, professional-looking garage floor that can be used almost immediately
after installation.
In this guide, we explain how to install modular garage floor tiles step by step, including how to
prepare your garage floor, where to start laying your tiles, how to cut around walls and obstacles, and
how to achieve a professional finish.
If you would prefer to follow along with a video, you can check out our YouTube tutorial for a visual
walkthrough.
What Are Modular Garage Floor Tiles?
Garage Style modular floor tiles are heavy-duty interlocking tiles designed specifically for garages,
workshops, showrooms and other demanding environments. Unlike the cheaper copies our tiles are
made using premium raw material meaning they are chemically resistant and backed by our industry
leading 10 year manufacturers warranty.
Each tile simply connects to the next using an interlocking system, allowing an entire garage floor to
be fitted without permanently fixing the flooring to the concrete underneath.
Our premium smooth PVC garage floor tiles measure 500mm x 500mm, meaning four tiles cover
approximately 1m².
Because they are modular, individual tiles can also be removed or replaced in the future if required.
What You’ll Need to Install Garage Floor Tiles
Before getting started, it helps to have everything ready.
For most modular garage floor installations you will need:
- Your garage floor tiles
- A rubber mallet
- Tape measure
- Marker or pencil
- Straight edge
- Suitable cutting tool, such as a jigsaw
- Safety equipment when cutting
- Edge ramps or finishing pieces where required
We recommend ordering approximately 5% extra flooring to allow for cuts around the perimeter of
the garage and any obstacles.
Step 1: Prepare the Garage Floor
One of the major benefits of modular garage flooring is that extensive floor preparation usually isn’t
required.
However, you should still start with a clean working area.
Remove everything possible from the garage and thoroughly sweep or vacuum the existing concrete
floor. Remove any loose debris, stones, screws or other objects that could prevent the tiles from
sitting correctly.
The existing floor does not have to look perfect. Modular flooring can be particularly useful for
covering tired, stained or unattractive concrete and creating a completely new finish.
Any major damage or significant uneven areas should, however, be investigated before installation.
Step 2: Plan Your Garage Floor Layout
Before clicking tiles together, spend a few minutes planning your layout.
Think about:
- Where you want different colours to sit
- Whether you’re creating borders or patterns
- Where cuts will be required
- The position of garage doors and access doors
- Fixed cabinets, pillars or other obstacles
- Which direction you want to work across the garage
Planning the floor first is especially important if you’re creating a two-colour or custom garage
flooring design.
Garage Style also offers an online floor configurator that allows you to enter your garage dimensions,
choose your tile style and colours, and visualise your layout before ordering.
Alternatively, our team can come to you and fit the flooring to your exact chosen design with no
adhesives required. We offer a full-service package including a design consultation, a range of
premium tiles with a 10-year warranty, edging, and professional installation by our experts.
Step 3: Start Laying the Garage Floor Tiles
Once you’re happy with the layout, you can begin connecting the tiles.
Position your first tiles carefully and begin building out across the garage. We recommend
interlocking one row of tiles together along the front of the garage first, then joining the ramp
sections on.
The interlocking edges of each tile are designed to connect together. Line the tiles up correctly and
use a rubber mallet where necessary to firmly connect the joints.
Close your garage door and push the ramps up against it, then continue to add tiles row by row.
One of the keys to a professional installation is making sure your first rows remain straight. Small
alignment errors at the beginning of an installation can become much more noticeable as you work
across a larger floor. We recommend leaving a 10mm expansion gap around walls and 2-3mm
around door frames.
Regularly check that your tiles remain correctly aligned as the floor grows, and be sure to open and
close your garage door to make sure it’s not catching on the ramp sections.
Step 4: Continue Across the Garage
Once the first section is established, the installation process becomes very straightforward.
Continue connecting full tiles across the main open area of the garage.
It is often easier to install as many complete tiles as possible before dealing with the smaller
perimeter cuts.
This allows you to quickly cover the majority of the floor while maintaining a consistent pattern.
Because the tiles interlock together, there’s no glue to spread and no coating that needs to dry.
Step 5: Measure the Perimeter Tiles
When you reach a wall, cabinet, pillar or other fixed object, you’ll normally need to cut your final row
of tiles.
Measure the available space carefully before marking the tile.
Check your measurement before cutting. If several tiles are being cut to the same dimension, a
straight edge or guide can help keep the finish consistent.
Remember that the flooring should not be forced tightly against every surrounding wall.
PVC flooring can expand and contract slightly as temperatures change, particularly in garages where
temperatures can vary considerably throughout the year.
Allow the appropriate expansion space around the perimeter rather than wedging the floor tightly
between two walls.
Step 6: Cut the Garage Floor Tiles
Once you’ve marked the tile, it can be cut to the required size.
Depending on the tile and the cut required, suitable cutting equipment can be used to produce a
clean edge.
For straight perimeter cuts, accurately marking the tile before cutting is one of the most important
parts of the process.
For obstacles such as pillars, door frames or fixed equipment, measure each side individually and
transfer the measurements onto the tile before cutting.
Always follow the appropriate safety procedures when using power tools.
Step 7: Install the Cut Tiles
Once cut, position the tile and connect it to the rest of the floor in exactly the same way as a
complete tile.
Continue working around the perimeter until the entire garage has been covered.
Take your time with these final cuts. They are normally the most visible part of the installation and
good measurements will make a major difference to the finished appearance.
Step 8: Finish the Garage Entrance
The entrance to the garage is another important area to finish correctly.
Depending on your flooring layout, ramped edging can be installed along exposed tile edges to
create a cleaner transition between the garage floor and the outside surface.
This creates a professional-looking finish while making it easier for vehicles and people to transition
onto the tiled floor.
Step 9: Check the Finished Floor
Once installation is complete, walk across the floor and check that all tiles have fully connected.
Look for any joints that haven’t completely engaged and tap them into position if necessary.
You can then return your vehicles, tools, cabinets and other items to the garage.
Unlike resin or painted garage floors, there is no lengthy curing period after installation.
Can You Install Modular Garage Floor Tiles Yourself?
Yes.
One of the biggest advantages of interlocking garage floor tiles is that they are extremely DIY-
friendly.
If you’re comfortable measuring and making a few simple cuts, you can transform an average garage
without needing specialist flooring experience.
For larger garages, complex designs or customers who simply want the perfect finish without doing
the installation themselves, Garage Style also offers professional installation nationwide.
Do Garage Floor Tiles Need to Be Glued Down?
In most normal garage installations, interlocking modular tiles are designed to create a floating floor
and do not need to be permanently glued to the concrete underneath.
The individual tiles connect together to create one large flooring system.
This makes installation faster and also means the flooring can potentially be lifted or individual tiles
replaced in the future.
Can Garage Floor Tiles Go Over Existing Concrete?
Modular garage flooring can be installed over many existing concrete garage floors.
This makes it an excellent option for garages where the concrete is stained, tired or simply
unattractive.
The floor should still be reasonably sound and any serious structural or moisture problems should be
addressed before covering it.
How Long Does It Take to Install Garage Floor Tiles?
Installation time will depend on the size and shape of the garage, the design you’ve chosen and the
number of cuts required.
However, because there is no adhesive or curing process involved, a modular garage floor can
generally be transformed far more quickly than many traditional flooring systems.
The majority of the installation involves simply positioning and connecting the tiles together.
How Much Will It Cost Me To Buy Tiles For My Garage?
Most garages fall into these ranges:
- Single garage (12–15m²): £350+vat – £500+vat
- Double garage (25–30m²): £730+vat – £1000+vat
- Large custom spaces: Price on enquiry
Why Choose Garage Style Modular Garage Flooring?
Garage Style has helped transform garages across the UK using premium modular flooring systems.
Our flooring is designed to combine durability with a high-end appearance, making it suitable for
everything from everyday home garages to workshops, car collections and commercial environments.
Our premium PVC smooth floor tiles are 500mm x 500mm, are available in a range of colours and
are backed by an industry-leading 10-year manufacturer’s warranty.
Customers can choose between DIY installation and our nationwide professional installation service.
Design Your Garage Floor
Want to see what your new garage floor could look like?
Use the Garage Style Floor Configurator to enter your garage size, choose your tile type and
colours and see your proposed floor layout and price.
Alternatively, contact the Garage Style team and we can help calculate exactly how many tiles you’ll
need for your garage.
Whether you’re transforming a single garage, creating the perfect home workshop or building a
high-end space for your car collection, modular garage floor tiles provide a quick, durable and great-
looking solution.
Ready to transform your garage? Explore our modular garage floor tiles or contact Garage
Style today for help designing your new garage floor.
